2 x 1/4 x 1/2 inch thick Block Magnets | BY048
BY048 Neodymium Magnets, 2 inch x 1/4 inch x 1/2 inch thick is made of Grade N42 NdFeB, Nickel Plated. The dimension is 2" x 1/4" x 1/2" thick, Thru Thickness magnetized. Pull force is approximately 35.73 lbs.
BY048 Neodymium Magnet's dimesion is 2" x 1/4" x 1/2" thick, Ni-Cu-Ni (Nickel) coating. Magnetization direction: Through Thickness
BY048 Neodymium Magnets, 2 inch x 1/4 inch x 1/2 inch thick is made of Grade N42 NdFeB, Nickel Plated. The dimension is 2" x 1/4" x 1/2" thick, Thru Thickness magnetized. Pull force is approximately 35.73 lbs.
Different grade, coating or magnetization direction can also be custom-made for this size. You can send us your inquiry for a quote. Discount can be applied for bulk quantities.
BY048
Data sheet
- Item Number
- BY048
- Material
- NdFeB
- Grade
- N42
- Size
- 2" x 1/4" x 1/2" thick
- Tolerance
- ±0.004"(±0.1mm)
- Coating
- Nickel Plated
- Magnetization Direction
- Thru Thickness
- Weight
- 30.7257 g
- Pull Force
- 35.73 lbs
- Thickness
- D. 9.53-12.7mm
- Length
- G. 25.4-50.8mm
- Width
- B. 3.18-6.35mm
BY048 Neodymium Magnets, 2 inch x 1/4 inch x 1/2 inch thick is made of Grade N42 NdFeB, Nickel Plated. The dimension is 2" x 1/4" x 1/2" thick, Thru Thickness magnetized. Pull force is approximately 35.73 lbs.
