3/4 x 3/4 x 1/2 inch thick Block Magnets | BCC8E

BCC8E Neodymium Magnets, 3/4" x 3/4" x 1/2" thick is made of Grade N42 NdFeB, Black Epoxy. The dimension is 3/4" x 3/4" x 1/2" thick, Thru Thickness magnetized. Pull force is approximately 34.46 lbs.

BCC8E Neodymium Magnets is made from high perfermance N42 NdFeB. The dimesion is 3/4" x 3/4" x 1/2" thick, Black Epoxy coating. Pull force: 34.46 lbs. Magnetization direction: Through Thickness

BCC8E Neodymium Magnets, 3/4" x 3/4" x 1/2" thick is made of Grade N42 NdFeB, Black Epoxy. The dimension is 3/4" x 3/4" x 1/2" thick, Thru Thickness magnetized. Pull force is approximately 34.46 lbs.

Different grade, coating or magnetization direction can also be custom-made for this size. You can send us your inquiry for a quote. Discount can be applied for bulk quantities.

BCC8E

Data sheet

Item Number
BCC8E
Material
NdFeB
Grade
N42
Size
3/4" x 3/4" x 1/2" thick
Tolerance
±0.004"(±0.1mm)
Coating
Black Epoxy
Magnetization Direction
Thru Thickness
Weight
1.22 oz. (34.57 g)
Pull Force
34.46 lbs
Thickness
D. 9.53-12.7mm
Length
E. 12.7-19.05mm
Width
E. 12.7-19.05mm
