55x10x8mm Block Magnets | B-W10H8L55-N48BE
B-W10H8L55-N48BE Neodymium Magnet, 55x10x8mm Block Magnet is made of Grade N48 NdFeB, Black Epoxy. The dimension is 55x10x8mm, Thru Thickness magnetized. Pull force is approximately 33.06 lbs (15.03kg).
B-W10H8L55-N48BE Neodymium Block Magnets is made from high perfermance N48 NdFeB. The dimesion is 55x10x8mm, Black Epoxy coating. Pull force: 33.06 lbs (15.03kg). Magnetization direction: Through Thickness
B-W10H8L55-N48BE Neodymium Magnet, 55x10x8mm Block Magnet is made of Grade N48 NdFeB, Black Epoxy. The dimension is 55x10x8mm, Thru Thickness magnetized. Pull force is approximately 33.06 lbs (15.03kg).
Different grade, coating or magnetization direction can also be custom-made for this size. You can send us your inquiry for a quote. Discount can be applied for bulk quantities.
B-W10H8L55-N48BE
Data sheet
- Item Number
- B-W10H8L55-N48BE
- Material
- NdFeB
- Grade
- N48
- Size
- 55x10x8mm
- Tolerance
- ±0.004"(±0.1mm)
- Coating
- Black Epoxy
- Magnetization Direction
- Thru Thickness
- Weight
- 33.000g
- Pull Force
- 33.06 lbs (15.03kg)
- Thickness
- C. 6.35-9.53mm
- Length
- H. 50.8-254mm
- Width
- D. 9.53-12.7mm
B-W10H8L55-N48BE Neodymium Magnet, 55x10x8mm Block Magnet is made of Grade N48 NdFeB, Black Epoxy. The dimension is 55x10x8mm, Thru Thickness magnetized. Pull force is approximately 33.06 lbs (15.03kg).
