10x2.3x3.3mm Block Magnets | B-W2.3H3.3L10-N50BE
B-W2.3H3.3L10-N50BE Neodymium Magnet, 10x2.3x3.3mm Block Magnet is made of Grade N50 NdFeB, Black Epoxy. The dimension is 10x2.3x3.3mm, Thru Thickness magnetized. Pull force is approximately 2.87 lbs (1.30kg).
B-W2.3H3.3L10-N50BE Neodymium Block Magnets is made from high perfermance N50 NdFeB. The dimesion is 10x2.3x3.3mm, Black Epoxy coating. Pull force: 2.87 lbs (1.30kg). Magnetization direction: Through Thickness
B-W2.3H3.3L10-N50BE Neodymium Magnet, 10x2.3x3.3mm Block Magnet is made of Grade N50 NdFeB, Black Epoxy. The dimension is 10x2.3x3.3mm, Thru Thickness magnetized. Pull force is approximately 2.87 lbs (1.30kg).
Different grade, coating or magnetization direction can also be custom-made for this size. You can send us your inquiry for a quote. Discount can be applied for bulk quantities.
B-W2.3H3.3L10-N50BE
Data sheet
- Item Number
- B-W2.3H3.3L10-N50BE
- Material
- NdFeB
- Grade
- N50
- Size
- 10x2.3x3.3mm
- Tolerance
- ±0.004"(±0.1mm)
- Coating
- Black Epoxy
- Magnetization Direction
- Thru Thickness
- Weight
- 0.569g
- Pull Force
- 2.87 lbs (1.30kg)
- Thickness
- B. 3.18-6.35mm
- Length
- D. 9.53-12.7mm
- Width
- A. 0.00-3.18mm
B-W2.3H3.3L10-N50BE Neodymium Magnet, 10x2.3x3.3mm Block Magnet is made of Grade N50 NdFeB, Black Epoxy. The dimension is 10x2.3x3.3mm, Thru Thickness magnetized. Pull force is approximately 2.87 lbs (1.30kg).
