20x20x20mm Block Magnets | B-W20H20L20-N40
B-W20H20L20-N40 Neodymium Magnet, 20x20x20mm Block Magnet is made of Grade N40 NdFeB, Nickel Plated. The dimension is 20x20x20mm, Thru Thickness magnetized. Pull force is approximately 59.84 lbs (27.20kg).
B-W20H20L20-N40 Neodymium Block Magnets is made from high perfermance N40 NdFeB. The dimesion is 20x20x20mm, Ni-Cu-Ni (Nickel) coating. Pull force: 59.84 lbs (27.20kg). Magnetization direction: Through Thickness
B-W20H20L20-N40 Neodymium Magnet, 20x20x20mm Block Magnet is made of Grade N40 NdFeB, Nickel Plated. The dimension is 20x20x20mm, Thru Thickness magnetized. Pull force is approximately 59.84 lbs (27.20kg).
Different grade, coating or magnetization direction can also be custom-made for this size. You can send us your inquiry for a quote. Discount can be applied for bulk quantities.
B-W20H20L20-N40
Data sheet
- Item Number
- B-W20H20L20-N40
- Material
- NdFeB
- Grade
- N40
- Size
- 20x20x20mm
- Tolerance
- ±0.004"(±0.1mm)
- Coating
- Nickel Plated
- Magnetization Direction
- Thru Thickness
- Weight
- 60.000g
- Pull Force
- 59.84 lbs (27.20kg)
- Thickness
- F. 19.05-25.4mm
- Length
- F. 19.05-25.4mm
- Width
- F. 19.05-25.4mm
B-W20H20L20-N40 Neodymium Magnet, 20x20x20mm Block Magnet is made of Grade N40 NdFeB, Nickel Plated. The dimension is 20x20x20mm, Thru Thickness magnetized. Pull force is approximately 59.84 lbs (27.20kg).
