15mm dia. x 3mm thick Round Disc Magnets | D-D15H3-N38E
D-D15H3-N38E Neodymium Magnet, 15x3mm Disc Magnet is made of Grade N38 NdFeB, Black Epoxy. The dimension is 15mm dia. x 3mm thick, Axial magnetized. Pull force is approximately 5.69 lbs (2.59kg).
D-D15H3-N38E Neodymium Disc Magnets is made from high perfermance N38 NdFeB. The dimesion is 15mm dia. x 3mm thick, Epoxy coating. Pull force: 5.69 lbs (2.59kg). Magnetization direction: Axial (Poles on Flat Ends)
D-D15H3-N38E Neodymium Magnet, 15x3mm Disc Magnet is made of Grade N38 NdFeB, Black Epoxy. The dimension is 15mm dia. x 3mm thick, Axial magnetized. Pull force is approximately 5.69 lbs (2.59kg).
Different grade, coating or magnetization direction can also be custom-made for this size. You can send us your inquiry for a quote. Discount can be applied for bulk quantities.
D-D15H3-N38E
Data sheet
- Item Number
- D-D15H3-N38E
- Material
- NdFeB
- Grade
- N38
- Size
- 15mm dia. x 3mm thick
- Tolerance
- ±0.004"(±0.1mm)
- Coating
- Black Epoxy
- Magnetization Direction
- Axial
- Weight
- 3.976g
- Pull Force
- 5.69 lbs (2.59kg)
- Diameter
- E. 12.7-19.05mm
- Thickness
- A. 0.00-3.18mm
D-D15H3-N38E Neodymium Magnet, 15x3mm Disc Magnet is made of Grade N38 NdFeB, Black Epoxy. The dimension is 15mm dia. x 3mm thick, Axial magnetized. Pull force is approximately 5.69 lbs (2.59kg).
